CONNFLY Elec DS1011-34RBSiB7-B electronic connector with 34 contacts gray housing and standard latch design

Row Spacing : 2.54mm

Operating Temperature : -40℃~+105℃

Color : 黑色

Contact Plating : 金

Number of Positions or Pins : 2x17P

Number of PINs Per Row : 17

Number of Rows : 2

Pitch : 2.54mm

Connector Type : 牛角扣

Mounting Type : 弯插

Description : Connector IDC Header Through Hole, Right Angle 34 position 2.54mm

Mfr. Part # : DS1011-34RBSiB7-B

Package : Through Hole,Right Angle,P=2.54mm

Model Number : DS1011-34RBSiB7-B

Contact Now

Product Overview

This product is an electronic component from CONNFLY ELECTRONIC CO. LTD, designed for various electrical applications. It offers robust performance with specified electrical and environmental characteristics.

Product Attributes

Brand: CONNFLY ELECTRONIC CO. LTD
Origin: Not specified
Material: Not specified
Color: Gray (Housing color)
Certifications: Not specified

Technical Specifications

No. of Contacts	Mounting Type	Housing Type	Contact Plating	Housing Color	Lock Type	DIM (mm)	Electrical Characteristics	Environmental Characteristics
10, 14, 16, 20, 24, 26, 30, 34, 40, 50, 60, 64	Standard latch, Special latch	V/T Type, R/A Type	Si: Full Gold flash, B: Level B, 3A: Level 3A	A: Gray, B: Black Housing	Standard latch, Big latch housing	7: 7.90mm, 4: 4.50mm	Contact resistance: 20m Max. INITIAL, Dielectric withstanding voltage: 500V AC(rms) for 1 minute	Temperature: -40C~+105C
